Alfen | AC Public (charging column, dual socket)
Eve Double PG-line
Compatibel. Verbind en beheer je Eve Double PG-line met Plugchoice via OCPP, naast elk ander merk.
Waar te koop
Shops die we volgen en die deze laadpaal verkopen, goedkoopste bekende prijs eerst. Prijzen komen uit openbare listings en zijn exclusief installatie tenzij vermeld.
Nog geen gevolgde shops voor deze laadpaal.
Specificaties
Elke waarde toont zijn bron en de datum waarop hij is gelezen. Een vinkje markeert data bevestigd door een tweede, onafhankelijke bron.
Identification
- Brand
- Alfen✓✓
- Product segment
- AC Public (dual socket column)✓✓
- Range / variants
- Standard; DE Dual Grid meter / Dreipunktzahler (Eichrecht); RFID + Giro-e option✓✓
- Lifecycle status
- In production✓✓
- Form factor
- pedestal✓✓
Technical Specifications
- Dimensions
- 1637.8 x 350 x 437.5 mm✓✓
- Weight
- 80 kg✓✓
- Charging capacity
- 2 x 22 kW✓✓
- Number of outlets
- 2✓✓
- Communication protocol
- OCPP 1.5, 1.6, 2.0.1✓✓
- Network interfaces**
- Ethernet, 2G, 4G✓✓
- User interfaces
- 7in TFT display, status LEDs, RFID✓✓
- Internal energy meter
- 4-quadrant, MID, Eichrecht certified✓✓
- Power connection
- Single or dual feeder cable✓✓
- Standby consumption
- 9-12 W✓✓
- Current type (AC / DC)
- AC✓✓
- Charging mode (IEC 61851)
- Mode 3✓✓
Physical
- Height (mm)
- 1637.8✓✓
- Width (mm)
- 350✓✓
- Depth (mm)
- 437.5✓✓
- Enclosure material
- 304 stainless steel + fibreglass polyester✓✓
- Color options
- RAL 7043 Traffic Grey (body), RAL 9016 Traffic White (front)✓✓
- Mounting options
- Ground✓✓
Electrical
- Rated voltage
- 400V (3x230V)✓✓
- Rated / max output current
- 32 A✓✓
- Max power 3-phase
- 22 kW per socket✓✓
- Grid frequency
- 50 Hz✓✓
- Max upstream fuse / breaker
- 32A gG fuse; 40-80A main switch✓✓
- Internal fuses
- gG 32 A✓✓
- Surge protection level
- Type 1+2 pre-installed✓✓
Connector
- Connector type
- Type 2✓✓
- Socket / cable / shutter
- Type 2 socket, lockable✓✓
Metering
- Meter accuracy class
- MID, Eichrecht certified✓✓
- MID certified
- Yes✓✓
- Eichrecht certified
- Yes✓✓
Connectivity
- Cellular (4G/LTE)
- Yes✓✓
- Ethernet
- Yes✓✓
- RFID / NFC
- Yes✓✓
- OCPP versions
- OCPP 1.6;OCPP 2.0.1✓✓
Smart / load management
- Dynamic load balancing
- Yes✓✓
- Group / static load balancing
- Optional✓✓
- Load-balancing measurement source
- P1, Modbus TCP/IP✓✓
Safety detail
- Built-in RCD / RCBO type
- Type B✓✓
- Earth fault protection
- RCD 4P 40A, 30mA, Type B✓✓
- Overload / overcurrent protection
- Firmware-based (two tables differ)✓✓
- Insulation class
- Class I✓✓
- IP rating
- IP54✓✓
- IK rating
- IK10✓✓
- Anti-theft / cable lock
- Lockable enclosure✓✓
Environment
- Operating temperature
- -25C to +40C✓✓
- Humidity range
- 5% to 95%✓✓
HMI / UX
- Display
- Yes, 7in TFT color✓✓
- LED status indicator
- Yes✓✓
Installation
- Wire terminal type
- Terminal block, max 25mm2✓✓
- Indoor / outdoor
- Indoor & Outdoor✓✓
- Installation style (backplate / direct mount)
- Charging pole✓✓
Compliance extra
- Standards (full list)
- IEC61851-1 (2017); IEC61851-22; TAB 4100; CE; LVD 2014/35/EU; VDE-AR-N 4100:2019-04; DIN EN 61439-2:2012-06✓✓
Market & positioning
- Markets sold / certified
- EU generic + Germany-specific meter variants✓✓
- Apparent product focus
- Public charging column✓✓
Certification & compliance
- CE / UKCA marking
- CE✓✓
- Safety certification body / number
- PTB, certified 19-07-2019✓✓
- AFIR ad-hoc payment
- RFID + optional Giro-e✓✓
Media & assets
- Official datasheet (link)
- https://eu-assets.contentstack.com/v3/assets/blt08d332658a89f766/blt7a0fdac7a324f390/679b89eab993b6c4fb6cecb8/90446200x-ACE-DS-1200-9.2-en_Datasheet_Eve_Double_PG-line.pdf✓✓
