AgeVolt | AC Residential Private
Wallbox Double
兼容. 通过 OCPP 用 Plugchoice 连接并管理您的 Wallbox Double，并可同时管理任意其他品牌。
购买渠道
我们追踪的、销售此充电桩的店铺，已知最低价优先。价格读取自公开商品页面，除非另有说明，不含安装费。
暂无追踪到销售此充电桩的店铺。
技术规格
每个数值都标明来源及读取日期。对勾表示该数据已由第二个独立来源确认。
Identification
- SKU(s)
- wallboxDouble_001✓✓
- Brand
- AgeVolt✓✓
- Manufacturer / OEM
- AgeVolt Slovakia s. r. o.✓✓
- Country of origin / design
- SK✓✓
- Product segment
- AC wallbox (commercial / light commercial)✓✓
- Range / variants
- Master (full OCPP controller; manages 1-100 chargers); Slave (dependent unit); TouchPoint (5.5 inch multi-touch display)✓✓
- Form factor
- wallbox✓✓
Technical Specifications
- Dimensions
- 410 x 315 x 162 mm✓✓
- Weight
- 13 kg✓✓
- Charging capacity
- 2 x 22 kW✓✓
- Number of outlets
- 2✓✓
- Communication protocol
- OCPP 1.6-J✓✓
- Network interfaces**
- WiFi; LTE/3G (optional); Ethernet 10/100 BaseTX✓✓
- Internal energy meter
- Yes✓✓
- Charging mode (IEC 61851)
- Mode 3 AC✓✓
Physical
- Height (mm)
- 410✓✓
- Width (mm)
- 315✓✓
- Depth (mm)
- 162✓✓
- Enclosure material
- Aluminium✓✓
- Tethered cable length
- 5 m✓✓
Electrical
- Number of phases
- 1 or 3✓✓
- Rated voltage
- 230 V / 400 V✓✓
- Rated / max output current
- 32 A✓✓
- Max power 3-phase
- 22 kW✓✓
Connector
- Connector type
- Type 2✓✓
- Socket / cable / shutter
- Type 2 socket outlets or tethered cable options (5m or 7m)✓✓
Metering
- MID certified
- Yes✓✓
Connectivity
- WiFi
- Yes✓✓
- Cellular (4G/LTE)
- Optional✓✓
- Ethernet
- Yes✓✓
- RFID / NFC
- Yes✓✓
- OCPP versions
- OCPP 1.6✓✓
- Local API (Modbus / REST)
- Modbus TCP, Modbus RTU, MQTT✓✓
Smart / load management
- Dynamic load balancing
- Yes✓✓
- Smart app
- Cloud app✓✓
Safety detail
- IP rating
- IP54✓✓
- IK rating
- IK10✓✓
